Features
-
Installation
Surface mounted on the wall, 300 mm, 29 mm projection
You screw the 150 × 25 mm mounting plate to the wall, connect the wires to the terminal block and click the luminaire onto it. The plate is 8 mm thick and sits partly inside the luminaire.
-
Light
380 lm at 6W, 2700K
Integrated LED with CRI 90 and a 36° beam angle, upwards and downwards. Fixed colour temperature, not dimmable, energy class G.
-
Version
Black, powder-coated aluminium
Housing in powder-coated aluminium, Class I, 230V, with a 5-year warranty. The same wall light is also available in white, brushed brass and brushed bronze.
Application
Wall light in black, 300 mm long, 29 mm from the wall
At 300 mm long, the Box Tube 30 projects only 29 mm from the wall: the mounting plate sits partly inside the luminaire. It shines upwards and downwards with a 36° beam, in extra warm white (2700K), and is not dimmable. For dry indoor areas.
In the box
Scope of supply, per unit.
Included
- Fixture
- Light source
- LED driver
- Mounting plate
- Mounting hardware
- Manual
Specifications
Measurements are nominal. Check the dimensioned drawing before cutting.
Dimensions & Recessed Fit
- Mounting plate dimensions
- L 150 × W 25 × D 8 mm
- Dimensions
- H 300 × W 25 × D 29 mm
General & Mounting
- Article number
- 29W3T30010B2
- Indoor / outdoor
- Interior
- Appliance class
- Class I (earthed)
- Mounting (location)
- Wall
- Fixation (method)
- Surface
- IP rating
- IP20
- Number of light points
- 2
- Adjustability
- Fixed
Light
- Color mode
- White
- Socket type
- Integrated LED
- LED lifetime
- 30000 h
- Light output
- 380 lm
- Color rendering (CRI)
- 90
- Light source
- LED
- Light color
- 2700K
- Beam angle
- 36°
- Efficacy (lm/W)
- 63.33
- Total wattage
- 6 W
Electrical & Safety
- Light source replaceability
- Not replaceable
- Dim technology
- Non-dimmable
- Power source
- Mains (corded)
- Dimmable
- No
- Input voltage
- 230 V
Colour, Material & Finish
- Finish
- Powder coated
- Colour
- Black
- Material
- Aluminium
Energy label
The EU energy label and product information sheet of the light source.
Frequently asked questions
Questions we are regularly asked about this fixture and its variants.
How far does the Box Tube 30 project from the wall?
29 mm. The 150 × 25 mm mounting plate is 8 mm thick and sits partly inside the luminaire.
Is the Box Tube 30 dimmable?
No. The Box Tube 30 is not dimmable and has a fixed colour temperature of 2700K.
Can the Box Tube 30 be used in a bathroom or outdoors?
No. The Box Tube 30 is for indoor use in dry areas only.
What is in the box of the Box Tube 30?
The luminaire with integrated LED and driver, the mounting plate, wall plugs and screws, and the instruction manual.
Does the black Box Tube 30 give less light?
No. All four versions are registered in EPREL at 380 lm and 6W; the housing colour does not change the light output.
Documents
Datasheet and installation manual, free to download.
