Features
-
Version
Powder-coated aluminium in black, Deco ring in black
The housing is powder-coated aluminium in black; the lamps have a Deco ring in black. The Chuck 2 Deco comes with a black or white housing and a black, white, gold or silver ring. 5-year warranty.
-
Light
1160 lm, 2700K, CRI 90, 36° beam
The two 8W Zenkai GU10 LED lamps deliver 1160 lm together at 16W, extra warm white light at 2700K with a colour rendering of CRI 90. 36° beam, rated life 30000h, energy class F. Dimmable with a leading-edge (TRIAC) dimmer.
-
Installation
Surface mounted on the ceiling, footprint 160 × 80 mm
You take the base plate with the lampholders out of the housing, connect the mains cable to the terminal block and screw the housing to the ceiling with two screws. Then you fit the lamps in the lampholders and refit the base plate. No cut-out is needed; screws and plugs are in the box.
Application
Surface mounted downlight of 160 × 80 × 90 mm with two LED lamps, black, extra warm white 2700K
The housing is screwed directly to the ceiling; no cut-out is needed. It connects directly to 230V mains without a driver; Class I, for dry indoor use.
The two lamps with Deco rings come in the box: 2700K, CRI 90 and a 36° beam. Dimming works with a leading-edge (TRIAC) dimmer. The Chuck 2 is the same housing without lamps.
In the box
Scope of supply, per unit.
Included
- Fixture
- Lamp holder
- Light source
- Mounting hardware
- Manual
Specifications
Measurements are nominal. Check the dimensioned drawing before cutting.
Dimensions & Recessed Fit
- Mounting plate dimensions
- L 160 × W 80 mm
- Dimensions
- L 160 × W 80 × H 90 mm
General & Mounting
- Article number
- 07C300211BB2
- Indoor / outdoor
- Interior
- Serviceability
- Front access – relamping from below
- Appliance class
- Class I (earthed)
- Mounting (location)
- Ceiling
- Fixation (method)
- Surface
- IP rating
- IP20
- Number of light points
- 2
- Adjustability
- Fixed
Light
- Efficacy (lm/W)
- 72.5
- Light color
- 2700K
- Light output
- 1160 lm
- Color mode
- White
- Socket type
- GU10
- LED lifetime
- 30000 h
- Color rendering (CRI)
- 90
- Light source
- PAR16
- Beam angle
- 36°
- Total wattage
- 16 W
Electrical & Safety
- Light source replaceability
- Yes, by user
- Dim technology
- Phase-cut leading-edge (TRIAC)
- Power source
- Mains (corded)
- Dimmable
- Yes
- Input voltage
- 230 V
Colour, Material & Finish
- Colour
- Black
- Material
- Aluminium
- Finish
- Powder coated
Energy label
The EU energy label and product information sheet of the light source.
Frequently asked questions
Questions we are regularly asked about this fixture and its variants.
Which lamps come with the Chuck 2 Deco?
The Chuck 2 Deco comes with two 8W Zenkai GU10 LED lamps with Deco rings: CRI 90, 36° beam, rated life 30000h, energy class F. You choose the colour temperature, 2700K or 3000K. The lamps are dimmable with a leading-edge (TRIAC) dimmer and you can replace them yourself.
Can I use the Chuck 2 Deco in a bathroom?
No. The Chuck 2 Deco is for dry interiors only.
What do the two colours of the Chuck 2 Deco refer to?
The first colour is the housing, black or white; the second is the colour of the Deco rings of the lamps: black, white, gold or silver. Where both match, a single colour is shown. Dimensions and light output are the same for every combination.
What is the difference between the Chuck 2 Deco and the Chuck 2?
The housing is the same: 160 × 80 × 90 mm, powder-coated aluminium, screwed to the ceiling. The Chuck 2 Deco comes with the two Zenkai GU10 LED lamps with Deco rings in the box; with the Chuck 2 the lamps are ordered separately.
What is the luminous flux of the Chuck 2 Deco in 2700K?
The Chuck 2 Deco in 2700K delivers 1160 lm at 16W, with CRI 90 and a 36° beam.
Documents
Datasheet and installation manual, free to download.
