Features
-
Installation
Surface mounted on ceiling and wall, 112 mm projection
The same round base plate works on a ceiling and on a wall, so one article number covers both positions in the same project. At 112 mm this is the shallowest projection in the Glow range — usable in a passageway where a full globe reaches too far forward. Class II, so no protective earth is needed.
-
Light
560 lm at 6W, 3000K, CRI 90
Integrated LED behind a Ø150 mm opal glass globe: an even surface rather than visible dots. 93 lm/W at system level — energy class F — and a rated life of 30000 hours. The LED is not replaceable; the luminaire is serviced as a whole, with a 5-year warranty.
-
Dimming
Leading edge and trailing edge
The on-board driver works with TRIAC and ELV dimmers. In practice that means no dimmer swap and no re-measuring — whatever the project already specifies will normally work.
Application
For indoor splash zones, up to bathroom zone 2
IP44 covers splashing water, not jets. That specifies the luminaire for bathrooms up to zone 2, hallways, stairwells and utility rooms. It is not intended for outdoor positions, not even under cover — those call for a luminaire qualified for outdoor use.
The black version is specified where the luminaire may read as a graphic element: on a pale wall, in a run along a corridor, on a light ceiling. Against dark finishes it recedes instead.
In the box
Scope of supply, per unit.
Included
- Fixture
- Light source
- LED driver
- Mounting hardware
- Manual
Specifications
Measurements are nominal. Check the dimensioned drawing before cutting.
Dimensions & Recessed Fit
- Mounting plate dimensions
- Ø81 × D 7 mm
- Dimensions
- Ø15.0 × H 15.0 cm
General & Mounting
- Indoor / outdoor
- Interior
- Appliance class
- Class II (double insulated)
- Mounting (location)
- Ceiling, Wall
- Adjustability
- Fixed
- Fixation (method)
- Surface
- IP rating
- IP44
- Number of light points
- 1
Light
- Color mode
- White
- Socket type
- Integrated LED
- LED lifetime
- 30000 h
- Light output
- 560 lm
- Color rendering (CRI)
- 90
- Light source
- LED
- Light color
- 3000K
- Efficacy (lm/W)
- 93.33
- Total wattage
- 6 W
Electrical & Safety
- Light source replaceability
- Not replaceable
- Dim technology
- Phase-cut leading-edge (TRIAC), Phase-cut trailing-edge (ELV)
- Power source
- Mains (corded)
- Dimmable
- Yes
- Input voltage
- 230 V
Colour, Material & Finish
- Colour
- Black
- Shade / diffuser
- Opal glass
- Material
- Aluminium
- Finish
- Powder coated
Energy label
The EU energy label and product information sheet of the light source.
Frequently asked questions
Questions we are regularly asked about this fixture and its variants.
Which bathroom zone is it rated for?
Up to zone 2. IP44 covers splashing water but not jets, so zones 1 and 0 are out. The luminaire is for indoor use only — an outdoor position, even under cover, calls for a luminaire qualified for that.
How far does it stand off the surface?
112 mm, measured from the mounting surface to the furthest point of the globe. The front measures Ø150 mm. That makes this the shallowest of the three Glow models — the Mini projects 115 mm, the Mount 167 mm.
Can it go on the ceiling as well as the wall?
Yes, with the same round base plate and the same fixing. Only the position differs, so one article number covers both.
Which dimmer does it work on?
On leading-edge (TRIAC) and on trailing-edge (ELV). The driver is integrated; no external power supply is needed.
Is the LED replaceable?
No, the LED is permanently integrated. Rated life is 30000 hours; after that the luminaire is replaced as a whole. Warranty 5 years.
Does the black version give less light?
No. Light leaves through the opal glass globe; the colour of the base plate does not change the photometry. All four finishes deliver 560 lm at 6W.
Documents
Datasheet and installation manual, free to download.
